146 Operating Instructions Combics Indicators
Menu Structure
Time-dependent automatic data output 6.3
1 display update 6.3.1*
2 display updates 6.3.2
10 display updates 6.3.4
100 display updates 6.3.7
Data output: line format 7.2
For raw data: 16 characters 7.2.1
For other applications: 22 characters 7.2.2*
Data output: sign format 7.3
Plus sign deactivated 7.3.1
Plus sign activated 7.3.2*
XBPI
SMA
Modbus/TCP
Printer Printer configuration
YDP20 YDP20
Menus 5.1 to 5.4 same as for COM1
YDP14IS YDP14IS
LINE Strip printer*
label Label printer
uni-pri Universal printer
Menus 5.1 to 5.6 same as for COM1
YDP04IS* YDP04IS
LINE Strip printer*
label Label printer
lab ff Label printer with manual feed
Analog Analog data output port for PLC operation
Analog output: value 8.12
NET Net value* 8.12.1
GROSS Gross value 8.12.2
Analog output: error indicator 8.13
high High level (20 mA)* 8.13.1
low Low level (0/4 mA) when menu is open or
during calibration: 0/4 mA on this interface
8.13.2
Analog output: mode 8.14
0-max.l. Zero to maximum load* 8.14.1
min./max Minimum/Maximum values 8.14.2
Analog output: data output min./max. 8.15
min Min. (0/4 mA) input in kg 8.15.1
max Max. (20 mA) input in kg 8.15.2
Analog output: output value comparison 8.16
4 MA 4 mA measured value entry 8.16.1
20 MA 20 mA measured value entry 8.16.2
setup / com-wp Optional: multiple scale connection (Combics 2 only)
Off*
WP-2 Weighing platform 2
see unicom / wp-2
