Sartorius CP2202S User Manual

Cabling Diagram
Peripheral Device
PC PC
25-pin or 9-pin
23
204
32
58
66
75
Type of cable: AWG 24 specification
– For connecting a computer or other peripheral device to the balance/scale using the
RS-232-C/V24 protocol and cables up to 15 m (50 ft.) long.
V24
Balance/scale
62
