Common Specifications CW* P | S | FS
Maximum readability 31,250 scale intervals (not in legal metrology)
Accuracy class l (on models …-.CE)
Verification scale intervals <3000e, (single-range scale) or 2 + 3000e (multiple range scale acc. to EN45501)
Digital protective interface acc. to EN45501
Data interface Bi-directional RS-232C interface with control outputs (standard equipment)
Additional data interface optional
Display 20 mm LCD, 7-segment plus status symbols, backlit
Housing:
Material AISI 304 stainless steel
Dust and water protection
acc. to EN60529 CW1P, CW1NP, CW2P: IP44 (optional IP65)
CW1S, CW1NS, CW2S: IP67
Operating temperature range -10°C to +40°C
Power supply 100–240 VAC (–15/+10 %), 50–60 Hz, max. 17 W/23 VA
DC Supply optional 15.5–24 VDC (±10%), max. 12 W
AC Supply optional 13–17 VAC (±10%), 50–60 Hz, max. 12 W
Battery operations External rechargeable battery pack YBR10Z
Emissions Acc. to EN61326+A1 Class B (IEC 61326+A1)
Immunity to interference Acc. to EN61326+A1, industrial environment (IEC 61326+A1)
Electrical safety Acc. EN61010-1 (IEC 1010-1), EN60950 (IEC 950)
Model-specific Specifications (Platform Specifications)
Model code: CW...-L CW...-I CW...-LCE CW....-NCE (2 x 3000e)
Readability Readability Readability Weighing range 1 Weighing range 2
Weighing capacity 15000d 30000d 1x3000e Maximum capacity Readability Maximum capacity Readability
3 kg 0.2 kg 0.1 g 1 g 1.5 kg 0.5 g 3 kg 1 g
6 kg 0.5 kg 0.2 g 2 g 3 kg 1 g 6 kg 2 g
15 kg 1 kg 0.5 g 5 g 6 kg 2 g 15 kg 5 g
30 kg 2 kg 1 g 10 g 15 kg 5 g 30 kg 10 g
60 kg 5 kg 2 g 20 g 30 kg 10 g 60 kg 20 g
150 kg 10 kg 5 g 50 g 60 kg 20 g 150 kg 50 g
300 kg 20 kg 10 g 100 g 150 kg 50 g 300 kg 100 g
600 kg 50 kg 20 g 200 g 300 kg 100 g 600 kg 200 g
1500 kg 100 kg 50 g 500 g 600 kg 200 g 1500 kg 500 g
3000 kg 200 kg 100 g 1000 g 1500 kg 500 g 3000 kg 1000 g
Model-specific Specifications
CH = Combics High Resolution
1N = Combics 1N Indicator (CIS1N)
3 = Combics 3 Indicator (CIS3)
E = Epoxy
G = Galvanized
