Operation
There are two fundamentally different
types of display:
– display for analysis and test functions
– display for menu parameter settings
(e.g., Setup or Program menu)
Analysis and Test Functions
This display is divided into nine
sections.
Example: Moisture Analysis:
Drying Program Info/Status Line:
This line shows the following
information:
– Selected drying program (e.g., P1)
– Configured drying temperature
(e.g., 105
o
C)
– Criterion for end-point recognition
(e.g., Autom.)
– Current temperature
– Elapsed drying time
Busy Symbol:
The J symbol is shown here when
the moisture analyzer is processing a
function activated by pressing a key.
Plus/Minus Sign:
A plus or minus sign (F or H) is shown
here for the weight value or a calculated
value (such as a percentage).
Bar Graph:
The bar graph is shown during moisture
analysis if the “Initial Weight” option in the
drying program is set to On.
The following symbols may be
displayed here:
Bar graph showing interval
markers
- Target value –20%
= Target value
+ Target value +20%
Measured Value:
This section shows the weight or
calculated value.
Unit:
When the weighing system reaches
stability, the weight unit or calculation unit
is displayed here.
Graphic Symbols:
The symbols shown here indicate the
current operating status of the moisture
analyzer. Example:
Drying in progress
Print Symbol:
During the printout of the analysis results
and other data, the following symbol is
shown here:
P Printing
Function Line:
This line indicates the functions that can
be activated by pressing “Enter” (e.g.,
Setup menu, Program menu, “Tare”,
“Start”, or “Cal” (calibration)).
If an error occurs, the resulting error code
or message overwrites this line.
C Auto.
