Sartorius PMA.Evolution - Default Chapter; Table of Contents

Operating Manual EVO1X | LAB1X 3
Contents
Contents
1 About This Document.......................................4
1.1 Scope....................................................4
1.2 Symbols Used ...........................................4
1.3 User Information........................................4
2 Safety
........................................................5
2.1 General Safety Instructions.............................5
2.2 Installation Instructions ................................6
2.3 Intended Use............................................7
3 Device Overview
.............................................8
3.1 Front View ..............................................8
3.2 Rear View ...............................................9
3.3 Ex-link Converter/AC Adapter .........................10
3.4 Operating and Display Elements.......................11
3.5 Menu List ..............................................13
4 Installation
.................................................17
4.1 Unpacking and Equipment Supplied...................17
4.2 Selecting a Setup Location ............................17
4.3 Installing the Scale.....................................18
4.4 Supply Voltage.........................................18
4.4.1 AC Adapter Assembly (Optional) ..............18
4.4.2 Connecting the Scale..........................20
4.5 Anti-theft Locking Device .............................22
5 Commissioning
.............................................23
5.1 Leveling ................................................23
5.2 Warm-up Time .........................................23
6 Operation
...................................................24
6.1 Switching the Device On/Off ..........................24
6.2 Locking the Keypad/Weight Display ...................24
6.3 Zeroing/Taring .........................................24
6.4 Calibration/Adjustment................................24
6.4.1 Calibration.....................................25
6.5 Weighing...............................................25
6.5.1 Weighing with One Decimal Place ............25
6.5.2 Weighing with Two Decimal Places
(Not for Verified Models)......................26
6.6 Applications............................................26
6.6.1 Calculation by a Factor........................26
6.6.2 Weighing Using the Recalculation Function ..27
6.7 Menu Settings .........................................29
6.7.1 Accessing the SETUP Menu....................29
6.7.2 Configuring the Main Menu Settings . . . . . . . . .29
7 Care and Maintenance
....................................33
7.1 Cleaning................................................33
7.2 Maintenance ...........................................33
8 Malfunctions
...............................................34
9 Storage
.....................................................35
10 Disposal
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
11 Serial Number Coding
.....................................36
12 Technical Data
..............................................37
12.1 General Data ...........................................37
12.2 Model-specific Data ...................................38
12.3 Verified Models with EC Type Approval Certificate:
Model-specific Technical Data.........................38
12.4 Device Dimensions .....................................39
12.4.1 Model EVO1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
12.4.2 Model LAB1X ..................................39
12.5 USB Port (PC Connection) .............................39
12.5.1 Purpose ........................................39
12.5.2 Installing the Software Driver.................40
13 Accessories
..................................................41
14 Sartorius Service
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
15 Conformity & Licenses
.....................................42
15.1 EU Declaration of Conformity .........................42
