Chapter II Product Features and Parameters
2.1 Product Features:
- 2 sections of bracket arms, suitable for a wide range of models
- Bilateral manual unlocking, safe and reliable
- Tray height adjusted by thread, with the adjustable height of 70mm
- Minimum lifting height of 110mm, suitable for low riders
2.2 Technical parameters:
Rated lifting capacity 4000KG
Inner width of the post 2860mm
Height of the lift 3700mm
Minimum lifting height 110mm
Tray adjustment height 70mm
Maximum lifting height 1999mm
Telescopic range of 3-section bracket arm 720mm~1050mm
Telescopic range of 2-section bracket arm 820mm~1225mm
Motor parameters
AE5105-3 3PH, 380VAC, 2.2KW, motor with iron housing
AE5105 1PH, 220VAC, 2.2KW, motor with iron housing
Type of hydraulic oil IS0 46# anti-wear hydraulic oil
