DY03005 Users Manual
-10-
Overload Protection:
250mA/250V FAST Fuse (for "ΩVmA" terminal inputs)
10A/250V FAST Fuse (for "10A" terminal inputs)
Max. Allowable Input Current: 10A
(For inputs > 2A: measurement duration < 10 secs, and interval > 15 minutes)
Frequency Range: 40Hz - 400Hz
Response: Average, calibrated in rms of sine wave
[1] If the current being measured is > 10A, the display may show the value of the current; but the measurement is dangerous.
RangeFunctions
2mA
20mA
200mA
10A
1µA
10µA
100µA
10mA
±(1.3%+5)
±(1.3%+5)
±(1.8%+5)
±(3.0%+5)
" OL " shown on display
___________ [1]
Resolution Accuracy Overrange Indication
AC Current
