DY03005 Users Manual
-12-
Functions Range Remark
The approx. forward voltage drop of the diode will be displayed.
The built-in buzzer will sound if the resistance is less than about 20Ω.
The buzzer may or may not sound if the resistance is between 20Ω and 100Ω.
The buzzer will not sound if the resistance is more than 100Ω.
Open Circuit Voltage:
about 2.8V
Test Current: about 1mA
Open Circuit Voltage:
about 2.8V
Continuity test
Diode test
