Technical specifications
General terminal specifications
Item
Specification
Dimensions
470 / 300 / 55 mm (18.50 /
11.81 / 2.17 inches)
Total weight
8 kg (17.6 lbs)
Data rate
Minimum 4 Mbps full duplex,
up to 20 Mbps via HTS satellite
Batteries
2-3 hours transmit time
(additional hot-swappable
batteries pack are optional).
Frequencies
Tx 13.75 – 14.50 GHz
Rx 10.95 – 12.75 GHz
Polarization
Linear Horizontal / Vertical
V/H or H/V
EIRP
Typical 46 dBW
G/T
9 dB/K
Satellite modem
iDirect Evolution or UHP
Networks
Power consumption
130 W (MAX)
Secondary links
WLAN
Interfaces
2 x LAN, 1 x USB host, WLAN
Access Point (IEEE 802.11 b/g)
User interface
Satcube GUI, Display, Pointing
system
Water and dust protection
IP65
DC input
24 VDC
AC/DC input range
100 – 240 VAC, 47 – 63 Hz, 150
W
Ambient temperature
tolerance
-20°C (4°F) to 50°C (122°F)
