Appendix
Manual for the terminal’s GUI
The GUI has 3 main tabs: STATUS, SETTINGS, ABOUT. Functions for each tab is provided below.
STATUS | SYSTEM
• SATELLITE INFORMATION: Information about what satellite profile is currently selected
(using either the GUI or terminal display).
• TARGET: Theoretical positioning angles for maximum signal strength.
Figure 29 Status screen as seen when logged into the terminal web GUI.
