Satec PM130E Reference Guide

22
Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
0xB20A
0xB20B
Max. I3 Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
Maximum Total Values
0xB280
0xB281
Max. Total kW
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
0xB282
0xB283
Max. Total kvar
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
0xB284
0xB285
Max. Total kVA
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
0xB286
0xB287
Max. Total PF
Timestamp
-1000-1000
×0.001
sec
INT32
UINT32
R
R
Maximum Auxiliary Values
0xB300
0xB301
Not used 0 UINT32
UINT32
R
R
0xB302
0xB303
Max. In Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
0xB304
0xB305
Max. Frequency
Timestamp
0-Fmax
×0.01Hz
sec
UINT32
UINT32
R
R
Maximum Demands
0xB380
0xB381
V1/V12 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
0xB382
0xB383
V2/V23 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
0xB384
0xB385
V3/V31 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
0xB386
0xB387
I1 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
0xB388
0xB389
I2 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
0xB38A
0xB38B
I3 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
0xB38C
0xB38D
Not used 0 UINT32
UINT32
R
R
0xB38E
0xB38F
Not used 0 UINT32
UINT32
R
R
0xB390
0xB391
Not used 0 UINT32
UINT32
R
R
0xB392
0xB393
Maximum kW import sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
0xB394
0xB395
Maximum kvar import sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
0xB396
0xB397
Maximum kVA sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
0xB398 Not used 0 UINT32 R
