4 ASD-110 SATEL
14. Close the detector enclosure.
5. Battery replacement
The detector power supply battery (CR123A 3 V) ensures operation for about 2 years. A low
battery status (voltage drop to 2.6 V) is audibly indicated (by a beep every 40 seconds). The
information on low battery is sent to the ACU-100 controller / INTEGRA 128-WRL control
panel. To replace the battery:
1. If the detector is used in the ABAX system, start the service mode in the control panel.
2. Turn the cover counter-clockwise (Fig. 1) and remove it (Fig. 2).
3. Remove the discharged battery and dispose of in accordance with applicable
environmental regulations.
4. Install a new CR123A 3 V lithium battery.
5. Close the detector enclosure.
6. Press and hold down the test / reset button (designated with the letter A in Figure 1) to
make sure that the detector works. Alarm should be triggered after a few seconds.
6. Specifications
Operating frequency band................................................................... 868.0 MHz ÷ 868.6 MHz
Radio communication range ............................................................up to 500 m (in open area)
Power supply ..................................................................................lithium battery CR123A 3 V
Battery life expectancy...................................................................................... approx. 2 years
Standby current consumption .......................................................................................... 85 µA
Class according to EN 54-5 (thermal sensor) ..................................................................... A1R
Minimum static response temperature ..............................................................................54 °C
Maximum static response temperature .............................................................................65 °C
Operating temperature range................................................................................. 0 °C – 55 °C
Enclosure dimensions......................................................................................... ø108 x 61 mm
Weight............................................................................................................................... 170 g
SATEL sp. z o.o.
ul. Schuberta 79
80-172 Gdańsk
POLAND
tel. + 48 58 320 94 00
info@satel.pl
www.satel.pl
Hereby, SATEL sp. z o.o., declares that this detector is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC. The
declaration of conformity may be consulted at www.satel.eu/ce
