SATEL CA-6 5
2 – OUT2 trouble;
3 – OUT3 trouble;
4 – 230 V AC loss;
5 – battery trouble;
7 – time not set;
8 – monitoring trouble;
A – no voltage on telephone line;
B – telephone line trouble – wrong dial tone;
A – telephone line trouble – no dial tone;
B – control panel RAM memory error.
9. Using selected user functions
All the user functions are described in the full version of the user manual. Described below
are just a few selected functions.
9.1 Changing your own code
1. Enter the code and confirm using key. The , and LEDs will start blinking.
2. Press the 1 key.
3. Enter the new code (4 to 6 characters) and confirm with # key.
9.2 Zone bypassing
1. Enter the code and confirm using key. The , and LEDs will start blinking.
2. Press the 4 key
3. The LEDs designated by digits indicate the current zone status:
LED extinguished – the zone is not bypassed,
LED blinking – the zone is bypassed.
4. Using the keypad, enter the number of zone which is to be bypassed (if it is not bypassed)
or unbypassed (if it is bypassed).
5. Having selected the zones to be bypassed / unbypassed, press the # key.
Notes:
• For security considerations, the installer can reduce the number of zones that the user is
authorized to bypass.
• Bypassing the zones reduces the level of security. Prior to arming, make sure that there
are no accidentally bypassed zones, which can allow an intruder to gain access to the
protected area, despite the system being armed.
• If a zone is bypassed because of its malfunctioning (e.g. because of detector trouble), call
the service technician immediately to repair the fault.
