Satel ETHM-1 User Manual

1 General
The ETHM-1 module enables the INTEGRA, INTEGRA Plus and VERSA alarm control
panels to communicate via the Ethernet (TCP/IP) network. The data transmission is
encrypted using an advanced algorithm based on 192-bit key.
The module firmware can be updated using an application available on the www.satel.eu
website.
2 Typical Applications
 Configuration of the control panel by using the DLOADX program from a computer with
Internet access.
The feature is available for the INTEGRA Plus, INTEGRA (firmware version 1.03 or newer) and VERSA
control panels (firmware version 1.01 or newer).
 Management of the security alarm system by using the GUARDX program from a computer
with Internet access.
The feature is available for the INTEGRA Plus and INTEGRA control panels (firmware version 1.03 or
newer).
 Operation and configuration of the control panel by using a web browser which supports
JAVA applications.
The feature is available for the INTEGRA Plus and INTEGRA control panels (firmware version 1.03 or
newer).
 Operation and configuration of the control panel by using the MOBILEKPD / MOBILEKPD2
application from a mobile phone with Internet access. The mobile phone can become an
additional alarm system keypad.
The feature is available for the INTEGRA Plus and INTEGRA control panels (firmware version 1.03 or
newer).
The MOBILEKPD2 application can be installed on a variety of mobile devices running
the Android, iOS or another operating system which supports Java applications.
 Transfer of events from the control panel to the central monitoring station via the Ethernet
(TCP/IP) network. This allows you to significantly reduce the cost of reporting.
The feature is available for the INTEGRA Plus, INTEGRA (firmware version 1.04 or newer) and for the
VERSA control panels (firmware version 1.01 or newer).
 Integration of the control panel with other systems over the Ethernet (TCP/IP) network,
owing to the open-source communication protocol. This application is dedicated to the
companies dealing with integration of the object-oriented systems and requires
development of their own software.
The feature is available for the INTEGRA Plus and INTEGRA control panels (firmware version 1.06 or
newer).
Further information on the open-source communication protocol can be found at the
www.satel.eu site.

Satel ETHM-1 Specifications

Power

supply voltage	12 V DC ±15%
standby current consumption	120 mA
maximum current consumption	120 mA

Operating Environment

environmental class according to EN50130-5	II
operating temperature range	-10 to +55 °C
maximum humidity	93±3%

Weight and Dimensions

dimensions	68 x 140 mm
weight	64 g
