Satlink WS-6979 - 4.2 DVB-T;T2 Input and LCD Features; 4.3 Audio;Video Processing and Data Port


SymbolRate 2<Rs<45Mband(SCPC/MCPC)
DVB‐T/T2INPUT/DEMODULATION
ConnectorType FEMALEType
InputFrequency 48to862MHz 
SignalInputLevel‐79.5dBm(MAX)
ANTSupply 5V,12V/17VImax100mA
DemodulationType QPSK,16QAM.64QAM,256QAM
LCD FEATURES 
LCDType  TFTTRANSMISSIVE 
NumberofDots 480(RGB)x272
Activearea(WxH) 95.04x53.86mm
2

AVoutputinterface 
ConnectorType  3.5mmjack
VideoOutput CVBS,
Audiooutput StereoAudioL/Routput
HDMIoutputconnecter
Format HDMI1.3a
AVinputinterface
ConnectorType  3.5mmjack
Videoinput CVBS,
Audioinput StereoAudioL/Rinput
AUDIO/VIDEOPROCESSING
Videodecompression MPEG‐2MP@HL,MPEG‐1Decoding,MPEG‐4ASP@L5HD
resolution,H.264MP&HP@L4,HWJPEGdecoding
Resolvingrate PAL‐25frame@720*576,NTSC‐30frame@720*480,
Signalcompatibility Supportconversionfordifferentvideoformats
VideoFormat 4:3,16:9,ByPan&ScanandLetterBoxconversion
Audiodecompression
MPEG‐1LayerI/II ，MPEG‐2LayerI/II,
Audiooutputmode Stereo,Mono,R/L
DATASERVICEPORT
Connector USB
Dataprotocol USB2.0interface
Filemanagementsystem NTFS,FAT32,FAT16
