SATO CL4NX UHF User Manual

For inlays not included on this list, please contact your local SATO dealer or sales office.
www.satoworldwide.com
• Squiggle and Higgs are trademarks or registered trademarks of Alien Technology Corporation in the U.S. and other countries.
• Monza is registered trademark of Impinj, Inc.
Avery
Dennison
AD-171m5
[Impinj Monza5]
13.5-53.5 7-10 18 24 16 Short - - -
13.5-23.5 11-35 60 24 19 Standard
11-18 19-27 28-35
Avery
Dennison
AD-227m5
[Impinj Monza5]
47.5-57.5 0-10 31 24 19 Short - - -
47.5-57.5 13-36 38 16 11 Standard
13-20 21-28 29-36
Avery
Dennison
AD-232iL
[NXP UCODE G2iL]
- - - - - Short - - -
45-70 12-35 62 24 16 Standard
12-19 20-27 28-35
Avery
Dennison
AD-233m5
[Impinj Monza5]
40-55 0-4 24 24 19 Short - - -
40-70 15-37 63 23 17 Standard 15-21 22-29 30-37
Avery
Dennison
AD-235u7
[NXP UCODE 7]
35-50 0-5 20 24 12 Short - - -
35-65 10-40 59 19 12 Standard
10-20 21-30 31-40
Avery
Dennison
AD-318m5
[Impinj Monza5]
21-46 0-3 31 24 19 Short - - -
31-61 11-31 52 23 19 Standard
11-17 18-24 25-31
Avery
Dennison
AD-370u7
[NXP UCODE 7]
- - - - - Short - - -
18.5-48.5 67-90 86 17 14 Standard
67-79 80-90 -
Avery
Dennison
AD-224iL
[NXP UCODE G2iL]
47.5-57.5 0-10 24 24 19 Short - - -
47.5-62.5 16-37 41 24 15 Standard 16-22 23-29 30-37
Avery
Dennison
AD-317iL
[NXP UCODE G2iL]
- - - - - Short - - -
35.5-60.5 10-33 50 24 16 Standard
10-17 18-25 26-33
Avery
Dennison
AD-236u7
[NXP UCODE 7]
40-70 0-7 24 24 16 Short - - -
40-50 8-31 37 18 8 Standard
8-15 16-23 24-31
SMARTRAC
DogBone i
[NXP UCODE G2iL/iM]
- - - - - Short - - -
44-59 1-30 50 24 9 Standard
1-10 11-20 21-30
SMARTRAC
Short Dipole i
[NXP UCODE G2iL/iM]
- - - - - Short - - -
46.5-56.5 14-34 45 24 11 Standard
14-20 21-27 28-34
SMARTRAC
Short Dipole M4
[Impinj Monza4
(E/D/QT)]
46.5-56.5 0-1 16 24 13 Short - - -
46.5-56.5 12-36 48 24 15 Standard
12-20 21-28 29-36
SMARTRAC
Belt M5
[Impinj Monza5]
35-40 0-3 23 24 16 Short - - -
40-70 11-35 60 24 13 Standard
11-18 19-26 27-35
SMARTRAC
MiniWeb
[NXP UCODE G2iL/iM]
- - - - - Short - - -
45-60 18-35 47 24 12 Standard
18-23 24-29 30-35
SMARTRAC
Web I
[NXP UCODE G2iL]
17.5-22.5 5-8 61 24 12 Short - - -
12.5-27.5 34-49 93 24 12 Standard
- 34-41 42-49
SMARTRAC
WebLite
[Impinj Monza5]
23-33 0-5 36 24 23 Short - - -
33-63 14-37 45 23 18 Standard 14-21 22-29 30-37
SMARTRAC
Viper
[Impinj Monza4D]
55 0-10 20 24 16 Short - - -
55 15-35 25 10 7 Standard
15-21 22-28 29-35
SMARTRAC
Frog 3D
[Impinj Monza4
(E/D/QT)]
25-30 3-6 60 24 19 Short - - -
25-40 7-36 82 20 17 Standard 7-16 17-26 27-36
SMARTRAC
Belt
[NXP UCODE G2iL]
- - - - - Short - - -
50-55 16-36 41 24 15 Standard
16-22 23-29 30-36
SMARTRAC
Dogbone
[Impinj Monza 5]
- - - - - Short - - -
43-58 13-31 36 8 8 Standard
13-19 20-25 26-31
SMARTRAC
ShortDipole
[Impinj Monza 5]
46-56 0-3 19 20 18 Short - - -
46-61 20-34 31 10 9 Standard
20-24 25-29 30-34
Invengo
Invengo Great Wall
[Impinj Monza5]
47-62 0-2 30 24 20 Short - - -
47-57 11-37 36 18 15 Standard
11-19 20-28 29-37
Invengo
Invengo xWing
[Impinj Monza5]
34.5-49.5 2-4 25 24 18 Short - - -
39.5-64.5 7-34 54 20 19 Standard
7-15 16-24 25-34
CHECKPOINT
Champion-M5
[Impinj Monza5]
40-45 0-2 27 24 19 Short - - -
40-70 8-35 58 20 20 Standard
8-16 17-25 26-35
CHECKPOINT
WindAparrel-M5
[Impinj Monza5]
30-45 8-11 46 23 20 Short - - -
30-65 19-41 82 16 13 Standard
20-26 27-34 35-41
Position(mm) Power (dBm)
(Y=) Standard Antenna Position
(mm)
Region
Manufacturer
Inlay
[IC Chip]
Feed Direction
XYSWriteRead
Antenna
Pitch
Blue Yellow Green
CL4NX_Inlay_CG.fm Page 40 Monday, March 10, 2014 7:53 PM

SATO CL4NX UHF Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max Print Width	4.1 inches (104 mm)
Power Requirements	100-240V AC, 50/60 Hz
Resolution	203 dpi
Media Sensor	Reflective and Transmissive
Interface	USB, LAN, IEEE1284, RS-232C, Bluetooth
RFID	UHF
Supported Barcode Types	1D, 2D barcodes
Supported Media Types	Roll, Fanfold, Tag, Ticket
Operating Temperature	41°F to 104°F (5°C to 40°C)
Print Speed	Up to 10 ips (254 mm/s)
