Trailer Wiring
Additional wire length has been provided for
connecting trailer wiring to your vehicle. A loop of
five wires is stored below the jack, which is located
on the driver’s side of the cargo area. The wires are
fused in both the underhood and instrument fuse
block. See Instrument Panel Fuse Block on
page 410 and Underhood Fuse Block on page 411.
The wires do not have a connector and should be
wired to the trailer by a qualified electrical
technician. The technician can use the following
information when connecting a trailer wiring
harness to your vehicle.
• Yellow: Left Turn Signal
• Brown: Parking Lamps
• Light Blue: Stop Lamps
• Black: Ground Wire
• Dark Green: Right Turn Signal
When connecting a trailer harness, be sure you
leave it loose enough so the wiring does not bend
or break, but not so loose that it drags on the
ground. Store harness below jack in the cargo area
when it is not in use. Wrap the harness together
and tie it neatly so it will not be damaged.
300
