Sauder Carson Forge 416969 - Step 7: Attach Extension Rails; Separate slides from rails, attach rails to drawer ends

Step Step 7
416969 www.sauder.com/servicesPae 12
å
Separate the EXTENSION SLIDES (Z) from the EXTENSION
RAILS (Y) as shown in the upper diaram below. Be prepared,
the parts are reasy.
å
Fasten the EXTENSION RAILS (Y) to the DRAWER ENDS (C
and D). Use four GOLD 5/16" FLAT HEAD SCREWS (3S).
å
NOTE: For each EXTENSION RAIL, turn a SCREW into the hole
shown in the enlared diaram. Then, slide the inner cartride
of the EXTENSION RAIL in to fi nd the other hole that lines up
with the hole in the END. Turn a SCREW into this hole.
Open end
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Push the black lever in and pull the SLIDE from the RAIL.
Z Y
Y
Y
C
D
Q
R
Open end
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
