Sauder Carson Forge 416969 - Step 28: Assemble File Drawer; Assemble file drawer sides, bottom, and back

Step
416969www.sauder.com/services
Pae 33
Step 28
VIEW THE T-LOCK BOX VIDEO
å
Fasten the FILE DRAWER BACK (D78) to the FILE DRAWER SIDES (D14
and D15). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S).
å
NOTE: Be sure the FILE DRAWER BOTTOM (D716) inserts into the roove
of the FILE DRAWER BACK (D78).
å
Repeat this step for the remainin drawers usin the SMALL DRAWER
FRONTS (T), DRAWER SIDES (D107 and D108), DRAWER BACKS (D109),
and DRAWER BOTTOMS (D707)
12
3
å
Insert the FILE DRAWER SIDES (D14 and D15) at
an anle into the slot at each end of the FILE
DRAWER FRONT (S).
å
Slide the FILE DRAWER BOTTOM (D716) into the rooves
in the FILE DRAWER SIDES (D14 and D15) and FILE
DRAWER FRONT (S).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(12 used in this step)
30S
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
D14
D15
D716
D716
D14
D15
D78
D15
S
S
Unfi nished
surface
With the palm of your
hand, tap the DRAWER
BOTTOM down into
the roove.
D14
