Sauder Carson Forge 416969 - Step 11: Attach Bottoms and Tighten Cams; Fasten bottoms to ends and tighten cams; Caution: Do not stand unit upright without back

Step
å
Fasten the BOTTOMS (J) to the ENDS (A, B, C, and D).
Tihten eiht HIDDEN CAMS.
Step 11
416969 www.sauder.com/servicesPae 16
Start Tighten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
Surface
with
HIDDEN
CAMS
Surface
with
HIDDEN
CAMS
J
J
Unfi nished ede
Unfi nished ede
B
A
D
C
R
Q
R
Q
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
