Sauder Carson Forge 416969 - Assembly Tools Required; Part Identification

Table of Contents Assembly Tools Required
2-3
4-5
6-39
40-43
44-48
49-50
51
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
416969 www.sauder.com/servicesPae 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identifi cation to help identify similar parts.
A DOOR RIGHT END (1)
B DOOR LEFT END (1)
C
DRAWER RIGHT END (1)
D
DRAWER LEFT END (1)
E RIGHT UPRIGHT (1)
F LEFT UPRIGHT (1)
G KEYBOARD UPRIGHT (2)
H TOP (1)
I SMALL TOP (1)
J BOTTOM (2)
K MODESTY PANEL (2)
L KEYBOARD SHELF (1)
M BACK (1)
N BACK (1)
O DOOR (1)
P ADJUSTABLE SHELF (1)
Q LEFT FRONT LEG (2)
R RIGHT FRONT LEG (2)
S FILE DRAWER FRONT (1)
T SMALL DRAWER FRONT (2)
D14 FILE DRAWER RIGHT SIDE (1)
D15 FILE DRAWER LEFT SIDE (1)
D78 FILE DRAWER BACK (1)
D107 RIGHT DRAWER SIDE (2)
D108 LEFT DRAWER SIDE (2)
D109 DRAWER BACK (2)
D707 DRAWER BOTTOM (2)
D716 FILE DRAWER BOTTOM (1)
Electric drill with 1/4" bit
(ONLY in indicated step)
