Sauder Carson Forge 416969 - Hardware Identification

Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
416969 www.sauder.com/servicesPae 4
CONNECTOR
PLATE - 2
14G
FILE GLIDE - 2
4B
Z
EXTENSION SLIDE - 2
Y
EXTENSION RAIL - 2
(EXTENSION SET SHOWN SEPARATED)
40CA
CABINET RIGHT - 2
40CB
CABINET LEFT - 2
40CC
DRAWER RIGHT - 2
40CD
DRAWER LEFT - 2
8E
CORNER
ACCENT - 4
FOOT - 4
10E
BLACK DRAWER
LEFT - 1
X
BLACK DRAWER
RIGHT - 1
W
BLACK CABINET
LEFT - 1
V
BLACK CABINET
RIGHT - 1
U
7F
TWIST-LOCK
®
FASTENER - 4
10A
SLIDE CAM - 6
12E
TACK GLIDE - 12
CAM SCREW - 12
8F 14H
HINGE - 2
DOOR STOP - 1
4I
HIDDEN CAM - 32
1F
CAM DOWEL - 20
2F
