sauter FC 10 User Manual

FC-BA-e-1410 5
: The measured value higher than the upper limit
④ Test units: Displays selected measuring unit (N, kgf, ozf, and lbf selectable)
⑤ System time
⑥ Data transmission icon
⑦ Data storage icon
⑧ Analogue bar
⑨ Current measured value
⑩ Force direction Indicator - for tension:
- for compression:
1.3 Key Functions
Power: ON/OFF Storage / Back
Zero/Up Menu/Enter
Test Mode/Down
1.4 Specifications
2 Operation
2.1 Preparation
Confirm the model
This series force gauge has 5 models which can be selected, each model corre-
sponding to the capacity and resolution, shown in a table on the last page of this
manual. Select the appropriate model you need before use.
Accuracy
± 0.3% F.S.
Units
N, kgf, ozf, and lbf.(Selectable)
Display
160*128 matrix LCD with Backlight
Overload Capacity
150% of max. (LCD flashes beyond 110%
of max.)
Measurement mode
Track ,Peak and Preset
Data Sampling Rate
1000 Hz
Memory
500 data
Set Point
Programmable high and low limits
Power
3.6VDC 450mAH Ni-MH rechargea-
ble batteries
Charger / Adaptor
USB/BM charger, Input:110~240VAC
Temperature Effects
<0.03% of max per °C
Dimensions
140x 71.2x 35.5
mm
Weight 0.4 kg (0.9 lb)
