FH-BA-e-2020 7
3.4 Technical data external load cell (from 1kN)
Maximum
load
LxWxH
Thread type
Cable
length
1 kN
76x51x19mm
M12x1.75
Approx.
2,5m
2 kN
76x51x19mm
M12x1.75
5 kN
76x51x28mm
M12x1.75
10 kN
76x51x28mm
M12x1.75
20 kN
76x51x28mm
M12x1.75
50 kN
108x76x25,5mm
M18x1.5
100 kN
178x125x51mm
M30x2.0
