SawStop RT-LFT - Page 18

13
RT-LFT/RT-DCB OWNER’S MANUAL
7
Turn the router lift back over and reinstall it in the router table using the two at
head socket screws (1.13).
6
Hold the sprocket in place and use a 6mm hex wrench to tighten the socket head
cap screw (1.21) to secure the sprocket.
OFFSET
SPROCKET
1.21
1.45
1.22
1.13
1.13
