RT-LFT/RT-DCB OWNER’S MANUAL
PARTS INVENTORY
Parts and Hardware Lists
PAGES:
2-4
IF YOU CANNOT FIND AN ITEM ON THIS LIST, CHECK THE MOUNTING
LOCATIONS OR EXAMINE THE PACKAGING MATERIALS VERY CAREFULLY.
CERTAIN COMPONENTS MAY HAVE BEEN PRE-INSTALLED
FOR SHIPPING PURPOSES.
Four-Post Router Lift with Lock
Router Lift with 1-½” Phenolic Router
Table Insert Ring (1)
M6 x 1.0 x 25 Pan Head Phillips Screw (1)
Starting Pin Sleeve (1)
Elevation Handle Assembly (1)
M6 x 1.0 x 30 Flat Head Socket Screw (2)
Insert Wrench (1)
3.5” Router Reducer Collar (2)
3.25” Router Reducer Collar (1)
2.5mm Hex L-wrench (1)
3mm Hex L-wrench (1)
4mm Hex L-wrench (1)
6mm Hex L-wrench (1)
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
A
B
E
F
I
H
G
D
C
J
K
L
The Router Lift and Downdraft Dust Collection Box are shipped partially assembled.
Please unpack the parts carefully and conrm you have received each item on the
list below.
You will also need the following tools to complete the router lift assembly and installation:
• Phillips Head Screwdriver
• 4mm Hex Wrench (Included)
See Exploded View #1 on page 23 for more information.
• 8mm Hex Wrench
• 10mm Wrench
