RT-LFT/RT-DCB OWNER’S MANUAL
Throughout the manual, the exploded views are referenced to clarify the location
and name of each part. There are multiple exploded views in this manual, so
a decimal point system is used. The number before the decimal point refers to
the exploded view number (in this case, 1 and 2). The number after the decimal point
refers to the part number (as indicated by the number in the balloon in the exploded
view). For example, a part referenced as “1.1” would be the part labeled with a “1.1”
balloon in the exploded view #1.
• Exploded View #1: Four-Post Router Lift with Lock – See page 23
• Exploded View #2: Downdraft Dust Collection Box – See page 27
