SBC PCD2.M120 - Analogue Thermocouple Modules

Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
5
Input/output (I/O) modules
5-105
Analogue I/O modules
5.15 Analogue thermocouple modules
PCD2.W745 4-channel thermocouple modules for J, K … thermoelemets
Supported temperature sensors are:
● Thermocouples – TC type J, K
● Resistive temperature detectors – RTD’s type Pt 100, Pt 1000, Ni 100, Ni 1000
I/O modules and I/O terminal blocks may only be plugged in and removed when the
Saia PCD
®
and the external +24 V are disconnected from the power supply.
The module PCD2.W745 is described in the manual 26/796.
