Saia-Burgess Controls AG
Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26
Appendix
A-14
Order codes
A
Type Description Weight
Combined Analogue input and output modules
PCD2.W500 12 bit resolution, 2 input and 2 output channels for voltage signals 55 g
PCD2.W510
1
) 12 bit resolution, 2 input channels for current signals and
2 output channels for voltage signals
55 g
Combined Analogue input and output modules, electrically isolated
PCD2.W525 14 bit resolution, 4 input and 4 output channels 85 g
Analogue output modules, electrically isolated
PCD2.W605 10 bit resolution, Simple module: 6 channels 0 … 10 V (≥ 3 kΩ) 60 g
PCD2.W615 10 bit resolution, Simple module: 4 channels 0 … 20 V (≤ 500 Ω) 60 g
PCD2.W625 10 bit resolution, Simple module: 6 channels -10 V … +10 V (≥ 3 kΩ) 60 g
Weighing modules
PCD2.W710
1
) 18 bit resolution, weighing module, 1 weighing system for up to 4 weighing cells 40 g
PCD2.W720 18 bit resolution, weighing module, 2 weighing systems for up to 6 weighing cells 45 g
Temperature modules
PCD2.W745 16 bit resolution, Temperature module for up to 4 measurement inputs 40 g
Fast counting counting I/O modules
PCD2.H100 Counting module up to 20 kHz 40 g
PCD2.H110 General purpose counting and measuring module up to 100 kHz 42 g
SSI encoder modules
PCD2.H150 SSI interface module 42 g
Positioning modules for stepping motors
PCD2.H210 Motion control module for one stepper motor axis 42 g
Positioning modules for servo-drives
PCD2.H310
2
) Motion control module up to 100 kHz for servo-drives,
1 axis for 24 VDC encoder
48 g
PCD2.H311
2
) Motion control module up to 100 kHz for servo-drives,
1 axis for 5 VDC / RS-422 encoder
48 g
PCD2.H320 Motion control module up to 125 kHz for servo-drives,
2 axes for 24 VDC encoder
66 g
PCD2.H325 Motion control module up to 125 kHz for servo-drives,
2 axes for 5 VDC / RS-422 encoder or SSI absolute angle transmitter
(Slave only)
66 g
PCD2.H322 Motion control module up to 250 kHz for servo-drives,
1 axes for 24 VDC encoder
66 g
PCD2.H327 Motion control module up to 250 kHz for servo-drives,
1 axis for 5 VDC / RS-422 encoder or SSI absolute angle transmitter (Slave
only)
66 g
1) Special version, supplied on request
2) Depending on the encoder, the 5 VDC supply may be loaded with up to 300 mA.
