SBM MTH 100 DI User Manual

11
To confirm programming and move on to
next menu


M


To validate and move on to next value


On validation of Tn you go back to the
first MENU A display


To validate and move on to next value
ADJUST SETPOINTS ?
yes (M) / no ()
Tc = 17 * Tr = 10 * Tn = 00 °C
modify (+/-) / yes ()

+
-
or
To modify the flashing Tn value

Tc = 17 * Tr = 00 * Tn = 00 °C
modify (+/-) / yes ()

+
-
or
To modify the flashing Tr value

Tc = 00 * Tr = 00 * Tn = 00 °C
modify (+/-) / yes ()

+
-
or
To modify the flashing Tc value
ADJUST SETPOINTS ?
yes (M) / no ()
NOTE : setpoints settings range from 0º to
47 ºC in 1º C steps.
The 3 setpoints are linked :
Tn cannot be greater than Tr
Tr cannot be greater than Tc
DAY :

M
STEP
No :


To validate and move on to step no.


To validate
WEEKDAY PROGRAMMING ?
yes (M) / no ()
Su * n° 01  00 : 00 = Clr
next (+/-) / yes ()

+
-
or
To select the day of the week
Mo * n° 01  00 : 00 = Clr
next (+/-) / yes ()

+
-
or
To select the step no. of the day of the
week
Mo * n° 01  00 : 00 = Clr
modify (M) / exit ()
Example of programming for Monday

M


3.4 PROGRAMMING INPUT (based on the example on page 8)
 MENU A (ADJUST SETPOINTS)
DISPLAY QUESTIONS YOUR REPLY
 MENU B (WEEKDAY PROGRAMMING)
Setpoint
Step
Time
