10
Alcove Installation Requirements:
Whenever the stove is placed in a location where the ceiling height is less than 7’ tall, it is
considered an alcove installation. Because of the reduced height, the special requirements listed
below must be met.
Alcove installation:
Model Connector pipe A B C D E F G
Scan 60 USA Double wall 60 48 21 12 12.5 15 33
Scan 60 Canada Double wall 1525 1210 535 304 315 381 840
Scan 61 USA Double wall 60 48 21 12 12.5 13 33
Scan 61 Canada Double wall 1525 1210 535 304 315 330 840
