23
Slide the air tube collar (pos.2) to the left, swing the air tube (pos.1) down and remove it.
Replacement Part List SCAN 60 and 61.
Caution:
Use only original SCAN replacement part.
Do not use substitute materials.
Replacement part Part #
Glass panel for the door SCAN 60 57600011
Glass panel for the door SCAN 61 57610011
Gasket for the glass 55300019
Door gaskets 55300021
Baffle plate upper SCAN 60 54600000 091
Baffle plate upper SCAN 61 54610000 091
Baffle plate lower SCAN 60 54600000 0911
Baffle plate lower SCAN 61 54610000 0911
Firebox lining SCAN 60 53600000 091
Firebox lining SCAN 61 53610000 091
Upper part for shaking grate 50100110
Shaker grate, complete 50100111
Secondary air tube
Creosote Formation and the Need for Removal
When wood is burned slowly it produces tar and other organic vapors, which combine with expelled
moisture to form creosote. The creosote vapors condense in the relatively cool chimney flue of a
slow-burning fire. As a result, creosote residue accumulates in the flue lining. When ignited this
creosote makes an extremely hot fire.
The chimney connector and chimney should be inspected at least twice monthly during the heating
season to determine if a creosote buildup has occurred. If creosote has accumulated it should be
removed to reduce the risk of a chimney fire.
