24
CLEANING THE GLASS
Our wood-burning stoves are designed to prevent serious soot build-up on the glass. The best way to achieve this is to
make sure you have a good supply of combustion air. It is also very important that the wood is dry and the chimney
correctly dimensioned.
Even if you operate the stove in accordance with our instructions, a slight film of soot may still accumulate on the glass.
You can easily remove this film by wiping the glass down with a dry cloth and then with a cloth dampened with glass cleaner.
¬ Please note that the glass cleaner is not to get into contact with the gaskets, as this can discolour the glass
permanently.
¬ The glass cleaner must not come into contact with the painted surfaces, as these can be damaged.
DISPOSAL OF STOVE PARTS
Steel/cast iron Send for recycling
Glass Dispose of as ceramic waste
Combustion chamber
lining
Vermiculite and chamotte are not recyclable. Dispose of as waste.
Baffle plate Vermiculite is not recyclable. Dispose of as waste.
Gaskets Dispose of as waste
REMOVING THE BAFFLE PLATE AND THE BAFFLE UNIT
Be very careful when removing the baffle plate from the stove.
After the baffle plate has been removed, the baffle unit can be dismounted.
Lift up the baffle unit a little and tip it slightly backwards until it is free of the hole (1). Then slowly pull out the unit, until
it is free of the rear rails (2).
Baffle plate
Baffle unit
