5
* The stove can take logs up to 30 cm (horizontally placed).
** Intermittent operation in this context means normal
use of a wood-burning stove. In other words, you should
let the fire die down until only the embers are left before
refuelling.
The Scan 80-series is produced in accordance with type
approval for the product, which also covers the product’s
Assembly and Instruction Manual.
The Declaration of Performance (DoP) is available from
www.scan.dk
PLEASE NOTE!
You get the best use of the stove by using a top-down lighting method.
See "Instructions for heating".
Tested in accordance with EN 13240
CO Emission at 13% O
2
0,06 %
CO
Emission at 13% O
2
800 mg/Nm
3
Dust @ 13% O
2
<6 mg/Nm
3
No
x
@ 13% O
2
81 mg/Nm
3
Efficiency 84 %
Nominal output 6 kW
Chimney temperature EN 13240 195 °C
Temperature in flue conn. piece 233 °C
Amount of smoke 6,3 g/sec
Negative pressure EN 13240 12 Pa
Recommended negative pressure
in flue connecting piece
17-20 Pa
Required combustion air supply 10 m
3
/h
Fuel Wood
Fuel consumption 1,9 kg/h
Amount of fuel required to light 1,5 kg
Amount of fuel, max. 2,25 kg
(Reference to EN 13240: 2001/A2:2004)
Materials
Steel plate,
Cast iron
Galvanised sheet
Vermiculite
Surface treatment Senotherm
Max. log length 25 cm*
Weight Scan 80-1/2 ca. 104,4 kg
Weight Scan 80-3/4 ca. 110,0 kg
Flue conn. piece internal diameter 144 mm
Flue conn. piece external diameter 148 mm
Approval type Intermittent**
TECHNICAL DATA AND DIMENSIONS
