Number Description Number Description
1 Bearing SNR FD204 29 Top plate
2 Front part 30 Clamping strap
3 Clamping rail 31 Capacitor 25uf
4 M12 Nut 32 Motor 0,55 kw
5 Bearing shank 33 Coupling
6 Bearing housing (6203) 34 Toothed belt pulley 26 td. Ø20
6 Bearing housing (6303) 35 Toothed belt HTD600 8M20
7 Bearing 6203 2 RS 36 Toothed belt pulley 26 td. Ø14
7 Bearing 6303 2 RS 37 Guard for toothed belt
8 Bolt M12x75 38 Insex bolt M6x18
9 Round rod with plastic 39 Disc Ø6
10 Round rod 40 Wheel
11 Round rod 41 Bolt M10x30
12 16x16 stay 42 Disc Ø10
13 Round rod with plastic 43 Bronze bushing
14 Motor cover casing 44 Wedge 5x5x25
15 16x16 stay 45 Wheel shaft
16 Rubber splash guard 46 Wedge 6x6x20
17 Angle plate for splash guard 47 Wedge 5x5x25
18 Bearing SNR FCE204 48 Stop ring
19 Insex bolt M5x16 49 Chain wheel 12 td.
20 Retaining washer 50 Chain wheel 12 td.
21 Eccentric shaft 51 Stop ring
22 Bearing SNR FCE204 52 Gear bed plate
23 Disc for belt tightener 53 Gear VF44 1:60
24 Bearing shank for belt tightener 54 Gear ange
25 Bearing 6002 2 RS 55 Gear shaft
26 Pulley for belt tightener 56-58-59 Coupling
27 Disc Ø8 57 Bearing 6007 2 RS
28 Insex bolt M8x50 60 Bronze bushing 20x25
