Schaefer DMD 30 User Manual

14
Technical data | Models
7 Technical data
Supply voltage: 12 V ... 30 V (DC, smoothed current)
Current requirement: DMD 30-H1/V1: up to 45 mA
DMD 30-H2/V2: up to 75 mA
DMD 30-H3: up to 105 mA
Temperature range: 0°C to +65°C/149 °F
Luminosity: red: 49 mcd
green: 200 mcd
blue: 40 mcd
Addressing 1 out of n: with additional Encoder PCB up to 31 floors
Addressing binary/Gray: with additional Connector PCB up to 31 floors
In conformity with:
8 Models
As well as the standard, other models are available:
• splash-proof model IPX3 according to EN 81-72
• temper proof model for category 1 according to EN 81-71
In conformity with:
