Schaffner NSG 438 - Technical specifications

NSG 438
40
9 Typical pulse data
Contact-Discharge 8kV Contact-Discharge 8kV
pulse rising edge (t
r
ca. 0.8ns) current at 30ns and 60ns
Reference figure quoted in IEC / EN 61000-4-2 (2001)
1 ns / div.
A
30
25
20
15
10
5
0
20 ns / div.
A
30
25
20
15
10
5
0
I
peak
I
100 %
90 %
I at 30 ns
I at 60 ns
10 %
t
r
= 0.7 to 1.0 ns
t
