Schaffner NSG 438 - 14 Ordering Information

NSG 438
50
14 Ordering information
NSG 438 basic kit consisting of:
NSG 438 ESD Simulator complete with:
Carrying case
Base station
Pistol
Network IEC / EN 61000-4-2 (2001)
150pF / 330Ω
Test fingers, ball and point
Pistol stand
Earth cable
Operating instructions
Mains unit / Charger 80-240Vac
Order No.
NSG 438
Quantity
.............
Options Order No. Quantity
Discharge network ISO 10605, 150pF/ 2kΩ
INA 4381
Discharge network ISO 10605, 330pF/ 2kΩ
INA 4382
Discharge network, ANSI hand model
INA 4383
Discharge network, ANSI furniture model
INA 4384
Test finger for fast pulse rise times < 400ps
INA 4411
Tripod adapter INA 4421
Carrying bag for the base unit INA 4422
Opto-link to a PC with 10m opto-cable
INA 417B
Discharge network, special execution,
R and C are to be specified .... pF / .... Ω
xxx
Measurement adapter IEC 61000-4-2 (2001)
MD 101
Measurement adapter (IEC drat) MD 102
