Operating Instructions Electroblock EBL 211
11
Date: 22.01.2016
9110476 BA / EN
This feature provides an automatic float charge for the starter battery at up
to 2 A when the 230 V mains is connected to the electroblock.
5 Technical d etails
5.1 Mechanical d etails
130 x 275 x 170 (H x W x D in mm), including attachment feet
2.0 kg
PA (polyamide), gentian blue (RAL 5010)
Aluminium, powder coated, light grey (RAL 7035)
5.2 Electrical details
230 V AC voltage 10 %, 47--63Hz sinewave, protection class I
1.9 A
6-cell lead-gel or AGM batteries, 80 Ah and above
Dependent on the control panel: approx. 1 mA, plus consumption of refrige-
rator control electronics
Conditions for the measurement:
F approx. 10 minutes after disconnection from the mains
F 12.6 V battery voltage
F Battery alarm OFF
F Battery cut-out switch ON
F Lighting for operator and control panel OFF
F All consumers switched off
F 12 V main switch OFF
Loading of D+ output of the alternator by the electroblock approx. 0.5 mA
without current consumption on D+ point
12 V outputs A maximum of 90% of the nominal current
of the relevant fuse may be
drawn.
Frost protection valve output max. 0.1 A
D+ point 1 A for fusing D+ input with 2 A
Leisure area battery
Battery selector
switch setting
lead-gel AGM
Charging curve IUoU IUoU
Final charge voltage 14,4V/16h 14,7 V / 4 h
Charge current 18 A 18 A
Voltage for
trickle charge
13,7 V with automatic
switchover
13,7 V with automatic
switchover
Mains charging
starter battery
Dimensions
Weight
Casing
Front
Mains connection
Current consumption
Suitable batteries
Standby current from
leisure battery
D+ loading
Current-carrying
capacity
Battery charging via
mains connector
