36
|
GB
14.1 Long-term storage
Follow all cleaning procedures after each use.
Ensure the unit is thoroughly cleaned before
storing to prevent build-up of dried paint which
may cause blockages and stop the unit from
working.
1. Perform all cleaning procedures.
2. Remove the spray hose (1)
3. Remove the suction hose (11) from the suction
loosen the screw on the metal hose clamp suction
hose inlet port (16).
4. Remove the return hose (10) from the return hose
-
en the screw on the metal hose clamp return hose
inlet port (21).
5. Turn the machine upside down. Add 30 mls of
household oil or pump protector oil into each inlet
port.
6. Set the prime/spray lever (19) to "spray" position
7. Turn the pressure control dial (9) to the "low
spray" setting.
8. Hold a rag over the spray hose outlet port (18).
9. Switch on the machine for 5 seconds by press-
switch (14).
10. Set the prime/spray lever (19) to "prime" position.
11.
screwdriver to tighten the screw on the metal
hose clamp suction hose inlet port (16).
12. Replace the return hose (10) to the return hose in-
the screw on the metal hose clamp return hose
inlet port (21).
13. Wipe the sprayer housing with a clean dry cloth.
14. Store the sprayer and its accessories in a clean,
dry location, out of the reach of children.
15. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies
with the applicable European standards. The
customer‘s mains connection as well as the ex-
tension cable used must also comply with these
regulations.
m ATTENTION! The power supply cord of this ma-
chine has an equipment-grounding conductor and
a grounding plug. The plug must be plugged into
an appropriate outlet which is properly installed and
grounded in accordance with all local codes and or-
dinances.
m WARNING! Check the voltage! The voltage must
comply with the information on the rating label!
13. Technical data
Motor 220-240 V/50 Hz
Input power 650-750W
Rated current 2.8-3.3A
Max working pressure 3000PSI / 207 bar
Short circuit rating 5kA
IP rating IP23
Class rating I
Working pressure
0-3000PSI / 0-207
bar
Ma. Flow rate 1.1 l/min
Sound pressure level 97 db(A)
Sound power level 91 dB(A)
Vibration value 0.715 m/s²
Working environment
temperature requirement
5°C -40°C
Working environment
humidity requirement
30%-50%
Spray hose length 7.6m
Spray hose outlet connector 1/4-18-NPSM
Noise
Total noise values determined in accordance with EN
14462:2005.
Wear ear protection.
The impact of noise can cause damage to hearing.
Limit the noise to a minimum!
• Only use appliances which are in perfect working
order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
•
14. Storage and transport
Store the equipment and accessories out of children’s
reach in a dark and dry place at above freezing tem-
perature. The ideal storage temperature is between 5
and 30 °C. Store the electric tool in its original pack-
aging.
m ATTENTION! The appliance must uncondition-
ally be secured against falling or turning down
during transport.
The machine must only be lifted and transported on
its handle.
