7. Before commissioning
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, packaging and
transport safety devices (if applicable).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage.
• If possible, keep the packaging until the end of the
warranty period.
DANGER
The device and the packaging are not children‘s
toys! Do not let children play with plastic bags,
lms or small parts! There is a danger of choking
or su󰀨ocating!
• Before connecting the machine, make certain that
the data on the type plate matches with the mains
power data.
• Check the device for transport damage. Report
any damage immediately to the transport company
which was used to deliver the compressor.
• Install the compressor near the point of consump-
tion.
• Avoid long air lines and supply lines (extension ca-
bles).
• Make sure that the intake air is dry and free of dust.
• Do not install the compressor in a damp or wet
room.
• The compressor may only be used in suitable
rooms (with good ventilation and an ambient tem-
perature from +5 °C to 40 °C). There must be no
dust, acids, vapours, explosive gases or inamma-
ble gases in the room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in ar-
eas where work is conducted with sprayed water.
• The compressor may only be used outdoor briey
when the ambient conditions are dry.
• The compressor must always be kept dry and must
not be left outdoors after work is complete.
8. Attachment and operation
m Attention!
Always make sure the device is fully assembled
before commissioning!
You require the following for assembly:
1x open-ended spanner 14 mm
1x Phillips screwdriver
(not included in the scope of delivery)
8.1 Fitting the wheels (g. 3)
• Fit the supplied wheels (5) as shown.
Residual risks
Comply with the stipulated maintenance and safety
instructions in the operating instructions.
Remain attentive at all times when working, and keep
third parties at a safe distance from your work area.
Even when the device is being used properly, there
will always be certain residual hazards that cannot be
completely ruled out. The following potential hazards
can arise due to the type and design of the device:
• Unintentional starting up of the product.
• Damage to hearing if the stipulated hearing protec-
tion is not worn.
• Dirt particles, dust etc. can get irritate the eyes or
face despite wearing safety goggles.
• Inhaling swirled up particles.
Warning!
This power tool generates an electromagnetic eld
during operation. This eld can impair active or pas-
sive medical implants under certain conditions. In or-
der to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
6. Technical data
Mains connection
230 V∼ 50 Hz
Motor power 110 0 W
Operating mode S1
Compressor speed 2800 min
-1
Pressure vessel capacity approx. 24 l
Operating pressure approx. 8 bar
Theo. intake capacity approx. 230 l/min
E󰀨ective delivery quantity
at 7 bar
approx. 50 l/min
E󰀨ective delivery quantity
at 4 bar
approx. 80 l/min
E󰀨ective delivery quantity
at 1 bar
approx. 110 l/min
Sound pressure level L
PA
60 dB(A)
Sound power level L
WA
87 dB(A)
Uncertainty K
PA
/
WA
2.59 dB
Protection category IP20
Device weight approx. 21 kg
Max. altitude
(above mean sea level)
1000 m
The noise emission values have been determined in
accordance with EN ISO 3744:1995.
Wear hearing protection.
Excessive noise can result in a loss of hearing.
