Scheppach HL1000v User Manual

7
Sestavni deli, Slika 1–2
1 Ročaj
2 Rezilo za cepljenje
3 Cepilni steber
4 Vijak za nastavitev vpenjalne šape
5 Nastavljiva vpenjalna šapa
6 Upravljalna roka
7 Zaščita za ročaj
8 Podpora za mizo (sprednja)
9 Podpora za mizo (stranska)
10 Zaskočni kavelj
11 Cepilna miza
12 Pokrov za ventilacijo
13 Osnovno ogrodje
14 Kolesa
15 Stikalo in vtič
16 Prestavna ročica
17 Motor
18 Zaščitni lok
HL1000v
Sestavni deli
Hidravlični cepilnik drv HL1000v
Set dodatne opreme
Navodila za uporabo
Tehnični podatki
Dimenzija D/Š/V
830/620/1520
Višina mize mm
285/580/780
Delovna višina mm
900
Dolžina obdelovancev
cm
59/78/107
Moč ton
10,0
Moč batov cm
49
Hitros naprej cm/s
5,5
Hitrost vzvratno cm/s
13,0
Količina olja litri
7,0
Teža kg
128,0
Pogon
Motor V/Hz
400/50
Dovod P1 W
4000
Odvod P2 W
3000
Delovanje
S 6/40 %**
Hitrost motorja 1/min
1450
Zaščita motorja
da
Nivo hrupa dB(A)
88
Stopenjski menjalnik
da
Technical changes subject to change!
* Namestitev koles, slika 6.1 Na obeh straneh namestite
kolesa s podložko in jih zavarujte z opornico.
and parts see Fig. 1 to 3.
Controls and parts, Fig 1–2
1 Handle
2 Riving knife
3 Splitting column
4 Set screw for clamping lug
5 Adjustable clamping lug
6 Operating arm
7 Handle guard
8 Support for table (front)
9 Support for table (side)
10 Locking hook
11 Splitting table
12 Venting cap
13 Base
14 Wheels
15 Switch and plug
16 Stroke setting rod
17 Motor
18 Protective Bow
HL1000v
Scope of delivery
Hydraulic log splitter HL1000v
Accessory pack
Operating instructions
Technical data
Dimensions D/W/H
830/620/1520
Table height mm
285/580/780
Working height mm
900
Log length cm
59/78/107
Power max. t*
10,0
Piston stroke cm
49
Forward speed cm/s
5,5
Return speed cm/s
13,0
Oil quantity litres
7,0
Weight kg
128,0
Drive
Motor V/Hz
400/50
Input P1 W
4000
Output P2 W
3000
Operating mode
S 6/40 %**
Motor speed 1/min
1450
Motor protection
yes
Sound level dB(A)
88
Phase inverter
yes
Technical changes subject to change!
* The maximum achievable splitting power depends on the resist-
ance of the material to be split and can, due to influencing vari-
able, deflect to the hydraulic system.
**(Continuous-operation periodic duty; duty cycle (40%), cycle
duration (10 min))
