• Plane (1x)
• Push stick (1x)
• Slide block (2x)
• Open-ended wrench (1x)
• Allen wrench, small (1x)
• Allen wrench, medium (1x)
• Allen wrench, large (1x)
• Rubber foot (4x)
• Washer (4x)
• Allen key (4x)
• Original operating instructions (1x)
• Blade adjustment block (1x)
• Hand crank (1x)
• Locking screw (1x)
• Washer Locking screw (1x)
• Chip extractor adapter (1x)
• Chip extractor (1x)
• Parallel stop (1x)
• Planing knife cover (1x)
• Knife covering plate (1x)
• Allen screw (2x)
• Spring ring (2x)
• Washer large (1x)
• Hexagon nut, self-locking (1x)
4. Intended use
The surfacing and thicknessing plane is designed for
the surfacing and thicknessing of all types of whole
pieces of square, rectangular or chamfered con-
verted timber.
The machine is to be used only for its pre-
scribed purpose.
m WARNING!
The following work must not be carried out:
• Insert work (in other words any work which does
not extend over the full length of the workpiece)
• Recesses, tenons or cut-outs
• Planing highly warped timber in which there is
inadequate contact with the feed bench.
m The protective equipment on the appliance is
strictly prohibited to be disassembled, changed,
used in conict with the designation and it is pro-
hibited to attach any protective equipment of other
manufacturers.
The bridge guard must not be removed during ma-
chining. The unused part of the blade shaft must be
covered.
Requirements for operating staff
The appliance may only be operated and maintained
by persons familiarised with it and informed about
possible risks.
Never let children work with the appliance. Never
let adults work with the appliance unless they have
been properly trained.
The operating staff must carefully read the Operat-
ing Instructions before using the appliance.
Qualication: Apart from the detailed instructions
by a professional, no special qualication is neces-
sary for appliance using.
Minimum age: Persons over 18 years of age can
only work on the appliance. An exception includes
youngsters trained in order to reach knowledge
under supervision of the trainer during occupational
education.
Local regulations may stipulate the minimum age of
the user.
Training: Using the appliance only requires corre-
sponding training by a professional or the Operating
Instructions. No special training is necessary.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the manufac-
turer will be liable for any damage or injuries of any
kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial ap-
plications. Our warranty will be voided if the machine
is used in commercial, trade or industrial businesses
or for equivalent purposes.
5. Important information
General Safety Instructions
WARNING! When using electric tools basic safety
precautions should always be followed to reduce
the risk of re, electric shock and personal injury
including the following.
Read all these instructions before attempting to op-
erate this product and save these instructions.
Safe operation
1 Keep work area clear
- Cluttered areas and benches invite injuries.
2 Consider work area environment
- Do not expose tools to rain.
- Do not use tools in damp or wet locations.
- Keep work area weil lit.
- Do not use tools in the presence of amma-
ble liquids or gases.
3 Guard against electric shock
- Avoid body contact with earthed or ground-
ed surfaces (e.g. pipes, radiators, ranges,
refrigerators).
4 Keep other persons away
- Do not let persons, especially children, not
involved in the work touch the tool or the ex-
tension cord and keep them away from the
work area.
5 Store idle tools
- When not in use, tools should be stored in
a dry locked-up place, out of reach of chil-
dren.
6 Do not force the tool
- lt will do the job better and safer at the rate
for which it was intended.
