29
This also includes moments during which the power
tool operates without load and moments during which
other things regular maintenance and service of the
tool and the insertion tools, regular breaks and the ap-
propriate planning of the sequences of operation.
7. Unpacking
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, store the packaging until the warranty
period has expired.
• Familiarise yourself with the product by means of the
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and suocation!
8. Before commissioning
m ATTENTION!
Always make sure the device is fully assembled
before start-up!
Wheel kit (g. B + C)
To manually change the position of the plate compac-
tor, it can be equipped with the enclosed wheel kit.
wheel kit. The machine engine must not be operated as
long as the machine is on the wheel kit. Before starting
the machine, remove the wheel kit!
•
6. Technical data
Motor / Engine
1-cylinder-4-stroke-
OHV Motor for unleaded
gasoline
Displacement 270 cm³
Motor power 6,6 kW
Tank volume 6,5 l
Approx. amount of oil 0,95 l
Working plate size
730 x 450 mm
Compaction pressure 30,5 kN
Travel speed 20-25 m/min
Vibration strokes 4000 vpm
Compaction depth 50 cm
Max. permissible angle
of the motor
20°
Weight 158 kg
Noise and vibration
m Warning:
wear suitable hearing protection.
Noise characteristic values
Sound power level L
WA
Sound pressure level L
pA
Uncertainty K
wa/pA
Vibration characteristics
Vibration a
h
22 m/s²
Uncertainty K 1,5 m/s²
Note: The indicated sound levels have been deter-
mined according to a standardized testing procedure
other. Furthermore, these values are suitable to eval-
uate the loads that sounds can cause for the user in
advance.
Attention! Depending on how you will use the tool, the
actual values may deviate from the indicated values.
Take measures to protect yourself from noise pollution.
In this process it is important to take the complete se-
quence of operation into account.
