6. Technical Data
HS 520 HS 520
Article Number 5905108901 5905108902
Construction measurements:
Total length mm 860
Total width mm 775
Total height mm 990
Rocker support mm 735
Saw blade ø mm 500/505
Idle speed motor 1/min 2800 2800
Cutting speed saw blade m/sec 74 74
Weight kg 75 75
Power unit
Motor V/Hz 220 - 240 / 50 380 - 420 / 50
Input power P1 kW 2,6 3,0
Output power P2 kW 2,1 2,4
Operating mode S6 / 40% S6 / 40%
Rated current A 16 16
Work information
Cutting height Spar min. mm 170
Piece of wood max. mm 1200
Firewood max. mm 240 x 190
Reserve technical changes!
Specic noise values
The according to the EN 23746 for the sound pressure level resp. EN 31202 (correction factor k3 after supplement A.2
from EN 31204 calculated) for the sound pressure level on the working site ascertained noise emission value amounts
under the foundations of ISO 7904 supplement a performed working conditions to.
Sound pressure level in dB
Idle L
WA
/ Processing L
WA
98 / 104
Sound pressure level on working site in dB
Idle LqAeq / Processing LqAeq 89 / 95
The specied values are emission values and therefore should not at the same time be reliable working site values.
Although there is a correlation between emission and immision levels, it cannot unfailingly be derived if extra precautions
need to be taken or not. Factors, which inuence the actual availabe immusion value on working site, include the peculi-
arities of working area, other sources of noise, e.g. the number of machines and other adjoining processes. The allowed
working values could vary from country to country. However, the information should qualify the user, to be able to make
an estimation of the dangers and risks.
7. Scope of delivery
Remove all the parts from the box and check these for completeness (p.2). Remove all transport protection present.
1. Base frame with swivel, motor and switch
2. Wrench with locking pin
3. Rear strut
4. Foot, rear left and right
5. Saw blade
6. Strut, left and right
7. Wheel, 2 units
8. - 13. Accessories bag enclosed
14. Protective hood, assembled
15. Guard bracket
16. Protective cover
17. Swivel protection, 2 units
18. Protective ap
