1. Introduction
Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specied,
We recommend:
1 Read through the complete text in the operating
instructions before installing and commissioning
the device.
2 The operating instructions are intended to help
the user to become familiar with the machine and
take advantage of its application possibilities in
accordance with the recommendations..
3 The operating instructions contain important in-
formation on how to operate the machine safely,
professionally and economically, how to avoid
danger, costly repairs, reduce downtimes and
how to increase reliability and service life of the
machine.
4 In addition to the safety regulations in the operat-
ing instructions, you have to meet the applicable
regulations that apply for the operation of the ma-
chine in your country.
5 Keep the operating instructions package with the
machine at all times and store it in a plastic cover
to protect it from dirt and moisture. Read the in-
struction manual each time before operating the
machine and carefully follow its information. The
machine can only be operated by persons who
were instructed concerning the operation of the
machine and who are informed about the asso-
ciated dangers. The minimum age requirement
must be complied with.
6 In addition to the safety requirements in these
operating instructions and your country’s applica-
ble regulations, you should observe the generally
recognized technical rules concerning the opera-
tion of identical constructed machines.
2. Layout
1. Handle
2. Drive lever
3. Engine brake lever
4. Upper push bar
5. Quick-release lever
6. Petrol tank
7. Air lter
8. Side discharge
9. Wheel
10. Spark plug
11. Exhaust
12. Dip stick
13. Drive wheel
14. Wheel height adjustment
15. Discharge ap
16. Grass box
17. Pull starter
18. cable clips
19. Mulch insert
20. Spark plug wrench
21. Primer button
a 2 x round head screw M8
b 6 x washer
c 2 x plastic grip nut
d 2 x plastic star grip nut
e 2 x round head screw M8
f 2 x plastic grip nut
g 2 x xation slices
3. Scope of delivery
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available)
• Check that the delivery is complete.
• Check the device and its spare parts for possible
damage caused by transportation. In the event of
complaints, you must contact the distributor without
delay. Claims at a later stage will not be accepted.
• If possible, store the packaging until the warranty
period has expired
• Before handling the device, make yourself familiar
with it by reading the operating instructions.
• For accessories, consumables and spare parts,
only use original parts. Spare parts are available
from your stockist.
• Include our item number, the device model and
year of manufacture in your order.
•
m Attention!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts!
