www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
GB
|
29
2. Attach the lower push bar (4a) to both sides of the
mower with one screw (a), 1 washer small (c), 1
plastic star grip nut (d) each. Make sure that the
cables, which will be attached later, are not in the
way (Fig. 2-3).
3. Attach the upper push bar (4) on the lower push
bar with one quick-release lever (5), one washer
big (b), one washer small (c) and one plastic star
grip nut (d) each on both sides (Fig. 4-5).
4. Insert the pull start handle (17) in the designated
hook as shown in Fig. 6.
5. Fix the cables to the push bar with the cable clips
(18) provided (Fig. 7).
6. Grass box (16) - open it up and click the plastic
clips into position on the frame (Fig. 8).
7. Mowing with grass box:
Lift the discharge ap (15) with one hand and
hang the grass box (16) as shown in Fig. 9.
8. Mowing with side discharge:
Lift the side discharge ap and mount the side
discharge cover (8) (Fig. 15/15a). If the grass
box is attached, remove it and replace it with the
mulch insert.
9. Mulching:
If the grass box (16) is attached, remove it and
replace it with the mulch insert (19) as shown in
Fig. 10-12.
Setting the cutting height
m CAUTION!
Adjust the cutting height only when the engine is
switched off and the plug boot has been pulled.
• Before you begin to mow, check to ensure that the
blade is not blunt and that none of the fasteners are
damaged.
• To prevent any imbalance, replace blunt and/or
damaged blades as a set only (if applicable). To
carry out this check, rst switch off the engine and
pull the spark plug boot.
• The cutting height is centrally adjusted with the cut-
ting height adjuster lever (Fig.13/ Item 14). 7 differ-
ent cutting heights can be selected.
• Pull the adjuster lever out and select the desired
cutting height. The lever snaps into the desired po-
sition. (Fig. 13)
Preparing the area to be mowed
Before mowing, carefully examine the area. Remove
stones, sticks, bones, wires, toys and other objects
that may be ejected.
7. Unpacking
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available)
• Check that the delivery is complete.
• Check the device and its spare parts for possible
damage caused by transportation. In the event of
complaints, you must contact the distributor without
delay. Claims at a later stage will not be accepted.
• If possible, store the packaging until the warranty
period has expired
• Before handling the device, make yourself familiar
with it by reading the operating instructions.
• For accessories, consumables and spare parts,
only use original parts. Spare parts are available
from your stockist.
• Include our item number, the device model and
year of manufacture in your order.
•
m Attention!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts!
m DANGER
There is a risk of swallowing and suffocation!
8. Before starting the equipment
Assembling the components
Some parts of the mower come disassembled. For
quick and easy assembly, read and follow the instruc-
tions below.
Important! You will need the following additional tools
(not supplied) for assembly, and also for maintenance
work:
• Oil drip pan (for oil change)
• A 1 litre measuring jug (oil/petrol resistant)
• A petrol can (5 litres is sufcient for approx. 6 op-
erating hours)
• A funnel (suitable for the tanks petrol ller neck)
• Household wipes (to wipe up oil/petrol residue; dis-
pose of these at a lling station)
• A petrol suction pump (plastic, available from DIY
stores)
• An oil can with hand pump (available from DIY
stores)
• 0,5 litre of engine oil (SAE 30)
Assembly
1. Take the mower and attachment parts out of the
packaging and check that all parts are present.
