16. Stop rail
16a. Movable stop rail
16b. Set screw
17. Sawdust bag
18. Scale
19. Pointer
20. Set screw for drag guide
21. Drag guide
22. Set screw
23. Locking bolt
24. Screw for cutting depth limiting
24a. Rear knurled nut
25. Stop for cutting depth limiting
26. Adjusting screw (90°)
26a. Locknut
27. Adjusting screw (45°)
27a. Locknut
28. Flange screw
29. Outer ange
30. Saw shaft lock
31. Inner ange
32. Laser
32a. Cover
32b. Screw
33. ON/OFF switch laser
34. Guide bracket
35. Latched position lever
36. Tilt protection
37. Interlock carbon brushes
A.) 90° stop angle (not supplied)
B.) 45° stop angle (not supplied)
C.) Allen key, 6 mm
D.) Allen key, 3 mm
E.) Phillips head screw (Laser)
