7. Before starting the equipment
Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
Warning!
Always pull the power plug before making ad-
justments to the equipment.
The Electric Tiller is delivered unassembled. The
handles and the driving device must be assembled
and mounted befor using the Electric Tiller. Follow
the operating instructions step-by-step and use the
pictures provided as a visual guide to easily assem-
ble the machine.
Montage
Important!
You must fully assemble the appliance before
using it for the rst time!
Installing the central tubes (Pic. 3)
The central tubes (4) will be mounted one after an-
other at the frame tubing (5).
Lay down the rst central tube (4) on the frame tub-
ing (5) and push the carriage bolt (9) through the in-
tended hole.
Make sure that the square of the carriage bolt (9) ts
in the square of the central tube (4).
Subsequently the wing nut (10) will be mounted and
get hand-tighted. The same process also applies to
the second central tube (4).
Installing the Plastic cross-plate (Pic. 4)
Unscrew the tattping screw (11) from the cross-plate
(3)
Push the throttle handle (1a) and the handle (1b)
through the holes of the cross plate and align the
drill-holes from the handles and the Plastic cross-
plate. Subsequently screw in the tapping screw (10).
Installing the handles (Pic. 5)
Slide the handles (1a/b) between the central tubes
(4). The throttle handle need to be mounted on the
right side (seen in workdirection). The handle (1b)
need to be mounted on the left side. The power cord
(2) should be guided between the central tubes (4).
Now push the carriage bolts (9) through the intended
holes of the central tubes (4) and the frame tube (5).
Make sure that the square of the carriage bolt (8) ts
in the square of the central tube (4). Then screw on
the wing nut (10) and tighten it by hand.
Laying the power cord (Pic. 6/7)
Plug on the cable clip (12) on the right central tube (4)
(seen in workdirection). Now clip in the power cord
(2) into the cable clip (12). Additional clip in the power
cord (2) into the intended holder of the plastic cross-
plate (3).
2 Health damage caused by hand-arm vibrations
if the equipment is used over a prolonged period
or is not properly guided and maintained.
3. Even when all safety measure are taken, some
remaining hazards which are not yet evident
may still be present.
4. Remaining hazards can be minimized by fol-
lowing the instructions in Safety Precautions,
Proper Use and in the entire operating manual.
5. Injuries caused by the rotating blade.
6. Health risks caused by electricity. When incor-
rect or damaged mains cables are used. Fol-
lows instructions in the manual Electrical Con-
nections.
Warning! This electric tool generates an electro-
magnetic eld during operation. This eld can impair
active or passive medical implants under certain
conditions. In order to prevent the risk of serious or
deadly injuries, we recommend that persons with
medical implants consult with their physician and the
manufacturer of the medical implant prior to operat-
ing the electric tool.
6. Technical data
Main Voltage 230V~ 50Hz
Power Input 1500W
Working width 450 mm
Working depth max. 180 mm
LpA sound pressure level 82,6 dB(A)
K uncertainty 3 dB(A)
LwA sound power level 93dB(A)
K uncertainty 1,02 dB(A)
Vibration at the
handlebars
2,96 m/s
2
K uncertainty 1.5 m/s
2
Protection class II
Protection type IPX4
Weight 13,1 kg
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect work-
ing order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
