www.scheppach.com
GB
|
31
Number of teeth 24 (pre-assembled)
Riving knife (Thickness)
(mm)
2
Cutting depth max. 90°
(mm)
55
Cutting depth max. 45°
(mm)
41
Inclination steplessly 0 - 45°
Suction connection ø (inner) 35 mm /
ø (outer) 38 mm
Weight (without attach-
ments) (kg)
4,9
Dimensions L x W x H (mm) 340 x 260 x 235
Subject to technical changes!
Noise/vibration information
m WARNING! Health hazard!
Working without ear protection and suitable protective
clothing poses a health hazard.
• Wear ear protection and suitable protective clothing
when working with the device.
Measured in accordance with EN 62841-2-5 & EN
62841-1. The noise at your workplace may exceed 85
dB (A); protective measures are necessary in this case
(wear suitable ear protection).
Sound power level L
WA
106,6 dB(A)
Sound pressure level L
pA
95,0 dB(A)
Uncertainty K
wa/pA
3 dB(A)
The aforementioned values are noise emission values
and therefore, do not necessarily represent safe val-
ues for the workplace at the same time. The correlation
between emission and immission levels cannot reliably
provide for a conclusion as to whether additional cau-
tionary measures are necessary or not.
Factors that could aect the respective immission lev-
el present at the workplace involve the specication of
the work area, the surrounding area, the duration of
exposure, other noise sources etc.
You must also observe any divergences in national reg-
ulations with respect to permissible workplace levels.
The aforementioned information does, however, allow
the user to better assess dangers and risks.
m WARNING! This electric tool generates an electro-
magnetic eld during operation. This eld can impair
active or passive medical implants under certain con-
ditions. In order to prevent the risk of serious or deadly
injuries, we recommend that persons with medical im-
plants consult with their physician and the manufactur-
er of the medical implant prior to operating the electric
tool.
Residual risks
The machine has been built according to the state
of the art and the recognised technical safety re-
quirements. However, individual residual risks can
arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the „safety in-
structions“ and the „Proper use“ are observed along
with the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the ma-
chine in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be xed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual.
In doing so, your machine provides optimal perfor-
mance.
• Hands may never enter the processing zone when
the machine is in operation.
• Release the handle button and switch o the ma-
chine prior to any operations.
6. Technical data
Supply voltage 230 - 240 V~ 50Hz
Power (W) 1200
Protection class II
Idle speed n
o
(min
-1
) 5500
Carbide saw blade dimen-
sions (mm)
ø 160 x ø 20 x 2.4
